Viking Broiler Stays Cold
A Viking that bakes perfectly and then leaves the broiler stone cold has already ruled out most of the oven: the supply, the control and the door are all sound. That puts the fault on the broil side alone — its igniter on a gas oven, its element on an electric one. Run the checks below, then call Viking Repair Bellevue on (425) 696-2636.
What we usually find
- Most often
The broil igniter. On older gas models a glowing igniter that has failed never opens the broil valve, and a weakened one opens it only partway; on direct-spark models the burner sparks, the control cannot prove a flame, and it gives up.
- Sometimes
On dual-fuel and electric Viking ovens, a broil element that has burned through. With the oven cold, a split, a blister or a scorched spot along the loop usually marks where it broke.
- Rarely
The switching behind it: the thermostat contacts that feed broil, the heater coil inside the broil gas valve, or on electronic ovens a wire or the control board. Bake carries on because it runs through separate contacts.
What a working broiler does
On Viking’s infrared gas broilers the burner at the top of the oven heats a metal screen until it glows, and that glowing screen does the cooking. Viking’s guide for its self-clean gas ranges has you broil with the door closed, with the function knob on broil or convection broil and the temperature knob turned to its broil mark too.
A broiler that switches off and on during a session is not necessarily failing: the medium and low broil settings on Viking’s DSOE and DDOE electric wall ovens pulse their elements on purpose.
Glow, ticking or nothing
What you see through the window narrows it quickly. No glow and no sound on an older gas range points at the igniter or the circuit feeding it. A spell of ticking followed by silence on a direct-spark range means the burner is lighting poorly or its flame is not being sensed. On an electric oven, an element that stays dark while the bake side heats has usually opened somewhere along its length.
Safe checks before you call
-
Put both knobs on broil
On knob-controlled Viking gas ranges, turn the function knob to broil or convection broil and the temperature knob to its broil mark as well. Viking's guide asks for both, so set them that way before deciding anything has failed.
-
Close the door and watch the top
Shut the door, give it a few minutes and look through the window at the top of the cavity. A working infrared broiler brings its metal screen to a glow; an electric broil element glows along its loops.
-
Switch broil off and on once
On Viking's direct-spark gas ranges, a broiler that failed to light stays locked out until broil is turned off and set again. Do that one time only, and never if you can smell gas.
-
Look at an electric element cold
On dual-fuel and electric ovens, with the oven off and cool, look along the broil element for a split, blister or burned patch. On gas models leave the infrared screen alone: Viking says it needs no cleaning or adjustment.
-
Stop and hand it over
If none of that changes what the Viking is doing, leave it there and ring Viking Repair Bellevue on (425) 696-2636. Tell us what you already tried; it narrows the visit before we set out.
Asked about this
Can I keep baking while the broiler is out?
Usually, yes. Bake and broil run through separate igniters or elements and separate switching, which is why one can fail while the other carries on. If the bake side starts acting up too, stop using the oven. Any smell of gas means leaving the house and calling the gas utility first, then Viking Repair Bellevue on (425) 696-2636.
